RFID Smart Card

RFID smart card have small but sophis­ti­cat­ed com­put­ers inside them. They deliv­er the high­est lev­els of com­put­er secu­ri­ty to pro­tect your iden­ti­ty, pri­va­cy or finan­cial infor­ma­tion. RFID smart card tech­nol­o­gy is suit­able for uses such as iden­ti­ty cre­den­tials, pass­ports and pay­ment cards. The RFID smart card chip can be low fre­quen­cy, high fre­quen­cy and ultra-high fren­quen­cy.

HYD­card is a high qual­i­ty RFID smart card sup­pli­er. We can make your own PVC card, Gift Card, Mem­ber­ship Card, Trans­par­ent PVC Card, Busi­ness Card, ID Card, VIP Card, Key Tag, Cus­tom PVC Card, Mag­net­ic Card, Epoxy Card, RFID Card, Con­tact Smart Card, Card Hold­er, Lan­yard, Badge Reel and Sil­i­cone Wrist­band. If you have any inquiry, please feel free to con­tact us.

HYD pro­vide best RFID smart card. Many fea­tures can be sup­port­ed.

◆Mate­r­i­al: White PVC and clear PVC are the main mate­ri­als. We also have col­ored PVC mate­r­i­al.

◆Cus­tom shape: If you don’t want nor­mal CR80 cred­it card shape, we can pro­duce your own shape. You can also choose spe­cial shape from our exsit­ing moulds.

◆Thick­ness: From 0.18mm to 2mm.

◆Print­ing method: CMYK off­set print­ing, PMS silk print­ing and dig­i­tal print­ing.

◆Lam­i­na­tion: Glossy fin­ish, mat­te fin­ish, frost­ed fin­ish.

◆Bar­code: Many bar­code type sup­port­ed, such as code 128, code 39.

◆Vari­able data: Black, white, gold and sil­ver vari­able datas.

◆Sig­na­ture pan­el: Clear sig­na­ture pan­el, white sig­na­ture pan­el.

◆Mag­net­ic stripe: Hico mag­net­ic stripe, loco mag­net­ic stripe, black and col­ored mag­net­ic stripe.

◆Foil stamp­ing: Glod foil stamp­ing, sil­ver foil stamp­ing, rain­bow foil stamp­ing

◆Metal­lic fin­ish: Gold and sil­ver metal­lic fin­ish.

◆Emboss­ing: Gold and sil­ver emboss­ing.

◆Hole punch­ing: Round hole, slot hole, cus­tom hole.

◆Scratch off pan­el.

◆Relat­ed acces­sories: Card holder/carrier, lan­yard, badge reel.

Para­me­ters of Contact/Contactless chip

Chip mod­el	Brand	Type	Fre­quen­cy	Mem­o­ry	Read-Write time	Data con­ser­va­tion	Pro­to­cal
Mifare S50	NXP	Con­tact­less	13.56Mhz	1Kbyte	100000	10 years	ISO 14443A
Mifare S70	NXP	Con­tact­less	13.56Mhz	4Kbyte	100000	10 years	ISO 14443A
Mifare des­fire 2k	NXP	Con­tact­less	13.56Mhz	2Kbyte	500000	10 years	ISO 14443A
Mifare des­fire 4k	NXP	Con­tact­less	13.56Mhz	4Kbyte	500000	10 years	ISO 14443A
Mifare des­fire 8k	NXP	Con­tact­less	13.56Mhz	8Kbyte	500000	10 years	ISO 14443A
Mifare ultra­light	NXP	Con­tact­less	13.56Mhz	64byte	100000	5 years	ISO 14443A
Mifare PLUSS2K/X2K	NXP	Con­tact­less	13.56Mhz	2byte	200000	10 years	ISO 14443A
M1 PLUSS2K/4K	NXP	Con­tact­less	13.56Mhz	4byte	200000	10 years	ISO 14443A
I‑CODE SLI	NXP	Con­tact­less	13.56Mhz	1024bits	100000	40 years	ISO15693
HITAG1	NXP	Con­tact­less	125KHZ	2048bits	100000	10 years	ISO11784/785
HITAG2	NXP	Con­tact­less	125KHZ	256bits	100000	10 years	ISO11784/785
HITAG3	NXP	Con­tact­less	125KHZ	256/2048bits	100000	10 years	ISO11784/785
FM11RF08	FUDAN	Con­tact­less	13.56Mhz	1Kbyte	100000	10 years	ISO14443A
FM11RF32	FUDAN	Con­tact­less	13.56Mhz	4Kbyte	100000	10 years	ISO14443A
FM1208 series	FUDAN	Con­tact­less	13.56Mhz	8Kbyte	100000	10 years	ISO14443A
FM1204	FUDAN	Con­tact­less	13.56Mhz	4Kbyte	100000	10 years	ISO14443A
Legic256	Legic	Con­tact­less	13.56Mhz	256byte	100000	10 years
Ti2048	TI	Con­tact­less	13.56Mhz	256byte	100000	10 years	ISO15693
ID4001/4100	RUIXIN	Con­tact­less	125KHZ	–	100000	10 years	–
EM4200/4305	EM	Con­tact­less	125KHZ	–	100000	10 years	–
T5577	ATMEL	Con­tact­less	125KHZ	330bits	100000	10 years	ISO1178/785
U‑CODE HSL	HSL	Con­tact­less	915KHZ	2048bits	100000	10 years	ISO18000-6B
Alien9662(H3)	ATMEL	Con­tact­less	915KHZ	96bit EPC/512Bit user­mem­o­ry	100000	10 years	ISO18000-6C
Fm1216 series	FUDAN	Con­tact­less	13.56Mhz	16Kbyte	100000	10 years	ISO14443A
SLE4442/5542	SIEMENS	Con­tact	–	256byte	100000	10 years	ISO7816
SLE4428/5528	SIEMENS	Con­tact	–	1byte	100000	10 years	ISO7816
45DB041	ATMEL	Con­tact	–	528Kbyte	100000	10 years	ISO7816
AT88SC102	ATMEL	Con­tact	–	1024bits	100000	10 years	ISO7816
AT88SC1604	ATMEL	Con­tact	–	5704bits	100000	10 years	ISO7816
AT88SC153	ATMEL	Con­tact	–	2048bits	100000	10 years	ISO7816
24 series		Con­tact	–	1k-64k­bits	100000	10 years	ISO7816
